WattCycle 2.5kW 10kWh All-in-One AC Coupled Battery Storage System

Name: WattCycle 2.5kW 10kWh All-in-One AC Coupled Battery Storage System
Rating: 4.83 (41 reviews)

€2.139,99 EUR

⚡Important Notice: VDE and EN 50549 certifications for this product are currently in progress. Certification is expected between December 2026 and April 2027, depending on the certification body's processing timeline.

Add Storage to Your Existing Solar System

Compact 500 × 210 × 800mm all-in-one design
Designed to complement existing rooftop and balcony PV systems
Stores surplus solar energy instead of exporting it immediately
10kWh LiFePO4 battery for evening and overnight energy use
2.5kW rated output with up to 5kVA surge power
AC-coupled design works alongside compatible existing PV systems
Smart charging and discharging scheduling
Wi-Fi monitoring and remote control via WattCycle Home App
Supports solar self-consumption and time-of-use energy shifting
Backup power support for critical household loads
IP65 protection for flexible residential installation

Options

1 Pack 2 Pack 3 Pack 4 Pack

Free & Fast Shipping: Enjoy free shipping on your orders. The estimated shipping time varies by country. More information on Shipping Policy
Poland Local Warehouse: Orders are dispatched directly from our Local Poland Warehouse.
Instant Savings via Local Pickup: Contact us to pick up at our Polish warehouse for exclusive savings and avoid courier wait times.
Canary Islands (Spain) Shipping: You can shop our full range with ease via the GUANXE.COM App.

Shop with 100% confidence. We’ve removed all the risk.

xCotton Shipping Protection: Peace of mind is built in. Opt for xCotton Protection at checkout to safeguard your investment against loss, damage, or theft.
Zero-Cost Returns: If you aren’t completely satisfied, returns and exchanges are 100% FREE when your order is protected by xCotton. No hidden fees, no stress.
Learn more about xCotton Shipping Protection

Local EU Warehouses
VAT Included
5+2 Years Warranty
24/7 Customer Support

Payment Method

WattCycle 2.5kW 10kWh All-in-One AC Coupled Battery Storage System

€2.139,99 EUR

Feature
Tech Specs
Reviews

Meet 10kWh All-in-One AC Coupled Battery Storage System

Add Smart Storage to Your Home Solar System

The WattCycle 2.5kW 10kWh All-in-One AC Coupled Battery Storage System adds battery storage to an existing rooftop or balcony solar setup. Instead of sending all surplus solar power directly to the grid, you can store more of it for evening and overnight household use.

Use More of Your Solar, Buy Less from the Grid

Battery storage helps shift surplus solar energy from daytime to the hours when your home actually needs it. Instead of relying as heavily on grid electricity in the evening, stored solar power can support household consumption and improve overall solar self-consumption.

10kWh Storage for More Solar Self-Consumption

With 10kWh of battery capacity and 2.5kW rated output, the system helps capture surplus daytime solar energy and make it available when your home needs it later. This can reduce grid imports and help you use a greater share of the electricity generated by your own PV system.

Long-Life LiFePO4 Storage with Active Balancing

The integrated 51.2V 200Ah LiFePO4 battery provides 10kWh of energy storage for repeated household cycling. Active balancing and intelligent battery management help maintain cell consistency and support reliable long-term energy storage.

Backup Power When the Grid Is Unavailable

In addition to solar energy storage, the system can supply connected critical loads during an unexpected grid outage. Fast UPS switching helps minimise disruption to supported household electronics and essential equipment.

Built for Year-Round Residential Energy Storage

With IP65 protection and a wide operating temperature range, the system is designed for flexible residential installation environments. Clear status lighting also provides an easy visual indication of charging, Wi-Fi connection, inverter operation and system faults.

Monitor Your Energy System from Anywhere

Built-in Wi-Fi connects the system to the WattCycle Home App for convenient remote monitoring and control. Track energy status, manage supported settings and understand how solar generation, battery storage and grid power work together from your smartphone.

Designed to Complement Existing PV Installations

The AC-coupled architecture is intended for homeowners who already have a compatible rooftop or balcony solar system and want to add energy storage. Instead of replacing the existing PV hardware, the WattCycle system works as a storage layer alongside the current solar installation.

Smart Energy Scheduling Around Your Home

Automatically store excess solar energy when generation is high and use stored power later when household demand increases. Charging and discharging schedules can also be adjusted to better match solar production, household consumption and electricity tariff periods.

10kWh Storage in a Compact All-in-One Design

The system integrates battery storage, power electronics and smart energy control into one compact vertical enclosure. Measuring approximately 500 × 210 × 800mm, it reduces the space and complexity associated with installing multiple separate energy-storage components.

From Rooftop Solar to Stored Home Energy

In a conventional PV system, solar panels and the microinverter send electricity directly to the home or grid. Adding WattCycle AC-coupled storage creates an additional energy layer, allowing surplus solar generation to be stored and used later rather than immediately exported.

Store Solar by Day, Use It at Night

During the day, compatible rooftop or balcony PV systems generate electricity through the existing microinverter. The AC-coupled storage system can capture available surplus energy, then return stored power later when solar generation falls or household demand rises.

A Complete Smart Energy Storage Package

The system package includes the main energy storage unit, smart metering components, Wi-Fi antenna, grid charging cable and installation hardware. Together, these components help integrate solar generation, household demand, battery storage and grid interaction into one coordinated energy system.

Tech Specifications

General

Battery Technology	LiFePO4
Total Energy	10kWh
Rated Capacity	200Ah
Rated Voltage	51.2V
Dimensions (L × W × H)	500 × 210 × 800 mm
Weight	95 kg
Protection Rating	IP65
Display	Touch Screen
Communication Protocol	PYLON 485
Battery Cycle Life	≥8000 Cycles @ 25℃, 70% EOL
Standby Self-Consumption	<300μA

Battery

Battery Internal Resistance	≤13.9mΩ
Standard Discharge Capacity	≥200Ah
Charging Method	Constant Current / Constant Voltage (CC/CV)
Charge Cut-off Voltage	56–58.4V
Charge Stop Voltage	56.8V
Discharge Stop Voltage	44V
Input Current	Max. 100A
Output Current	Max. 100A
Discharge Current Protection	100A / 300S
Cell Overcharge Voltage	3.6V
Cell Overcharge Recovery Voltage	3.55V
Cell Overdischarge Voltage	2.6V
Cell Overdischarge Recovery Voltage	2.65V
Pack Overcharge Voltage	57.6V
Pack Overcharge Recovery Voltage	56.8V
Pack Overdischarge Voltage	41.6V
Pack Overdischarge Recovery Voltage	42.4V
State of Charge (SoC) Range	40%–60%
Balancing Method	Active Balancing
Battery Discharge Efficiency	94% @ 48VDC

BMS Protection

Charge Temperature Protection	High: 70℃ (Recovery 60℃) Low: -20℃ (Recovery -10℃)
Discharge Temperature Protection	High: 70℃ (Recovery 60℃) Low: -35℃ (Recovery -30℃)
Short-Circuit Protection	Recovery via "Remove Load" and "Charge/Discharge Removal"

Inverter

Rated Load	2.5kW
Surge Power	5kVA
Input Voltage Range	170–280Vac, L+N+PE
Input Frequency	48–51Hz
Output Voltage	208 / 220 / 230 / 240Vac
Output Frequency	50/60Hz ±0.1
Input Power Factor	≥0.95 PFC
Output Waveform	Pure Sine Wave
Switching Time	<10ms (UPS Mode, Auto-switch During Grid Failure)
Overload Capacity (Battery Mode)	5 min @ 105%–120% Rated Load; 10 s @ 120%–150% Rated Load
Max. AC Charging Current	50A
Grid-Tie Power	0–2500W
APP Function	Grid-tie Time & Power Management and Control
Insulation Withstand Voltage	42V DC Between Battery and AC Side, Leakage Current <1mA
Energy Saving Mode	<13W (Sleep, No Output); <30W (No-load Output)

Environment

Operating Temperature	-10℃ to 55℃ (14℉ to 131℉)
Operating Humidity	0–98%
